|Place of Origin:||Nanjing, China|
|Model Number:||CM/SE Series|
|Minimum Order Quantity:||1unit|
|Payment Terms:||T/T, L/C|
|Application:||All Kind Of High Filling Compounding & Modifying||Processing Product:||Carbon Black MB, Color Master Batch, Functional Master Batch Etc|
|Model:||CM-50/SE-100, CM-75/SE-120, CM-100/SE-150, SM-130/SE-180||Barrel:||Split Type Barrel|
|Capacity:||60-150kg/h,150-450kg/h, 300-800kg/h||Optional:||High Wear-resistance And Corrosion-resistance Screw And Barrel Liner Is Available|
Double-rotor continuous Mixer compounding extruder
Characteristic and advantage:
◆ Two stage configuration, the first step is a double-rotor continuous compounding main extruder, realizing the core processes such as plasticizing of polymers, kneading, mixing, etc; The second stage is single screw extruder or melt pump, which can realize low temperature pressure-building extrusion, at the same time increase independent operation and control variable.
◆ The double rotor mixing section is based on the design of tensile compounding mechanism. through the unique effects of folding, extrusion and kneading, it has the outstanding characteristics of low shear and low energy consumption, and can achieve better dispersion and mixing at lower equilibrium temperature.
◆ Unique host pressure control means, can on-line control of material residence time, filling rate, mixing degree and specific power consumption.
◆ With various types of rotor design, combined with the variable embedded cylinder structure, can realize the combination change and the flexible adjustment of the key structural parameters of the main machine, meeting the requirements for adapting to different materials and processes.
◆ Compared with the twin-screw, it has a larger working volume of the main extruder, and has better tolerance and adaptability to the size state of the raw material (fluffy or bulk material).
◆ The main extruder barrel is a split structure, which is convenient for cleaning and maintenance and material replacement.
◆ The double rotor is a double support structure at both ends, which strengthens the stress stiffness and avoids the direct friction contact and unnecessary wear between the screw and the cylinder in the twin screw extruder.
Typical operations and application:
All kinds of high filling compounding modification operations; high concentration carbon black masterbatch and color masterbatch, filling masterbatch and special masterbatch, functional masterbatch, flame retardant masterbatch, shield material, elastomer and rubber and plastic combination, etc.
|Model||Compounding extruder+single screwCompounding extruder + melt pump||
|Doublerotor continuous compounding extruder
||Rotor nominal diameter mm||50||75||100||130|
|Rotor L/D L/D||10||10||10||10|
|Rotor MAX speed rpm||1000||800||600||500|
|Main motor power kw||30||75/90||132/160||250/315|
|Single screw extruder
|Screw MAX rotation speed rpm||95||120||120||100|
|Motor power kw||15||37/45||45/55||55/75|
||Exhaust quantity ml/r||100||200||315/400||500/800|
|Motor power kw||4||7.5||15||22|
|Typical production capacity kg/h||60-150||150-450||300-800||650-1500|
